Hexagon Socket Cap Head Seal Screws
Type: Sealing screws, Sealing bolts, O Ring seal screws, Cap head seal screws
Material: Stainless steel
Finish: Natural
MOQ:2000PCS
Standard: Inches, Metric
Specification
socket cap head screws with an o ring which features a groove on the underside of the hexagon cap head. Seal screws are configured with a rubber O-ring (or a rubber element) that when squeezed, permanently seals out contaminants. This can include disinfectants, oil, gas, humidity, dust, moisture, or any debris or chemicals that can damage or destroy equipment while, at the same time, preventing equipment leakage of toxins (i.e. acid leakage from lithium batteries) into the environment.
The O-ring is made of Silicone rubber as standard but can be supplied in an extensive range of materials which makes them suitable for use in almost any environment without deterioration or loss of performance. Tubber O-rings are offered in Silicone, Fluorosilicone, Viton, Neoprene, Buna-N, Teflon, and EPDM material.
Cap head seal screws are often found in aircraft engines and motors, circuit boards, conveyor belts, LED Lighting materials, and robots that require high sealing power. Socket Head Seal Screws are available in a range of head types, such as low profile cap head Seal Screws, countersunk head cap Seal Screws, button cap Seal Screws, and button flange head Seal Screws. Materials are available in brass and stainless steel or carbon steel.
| Brand | Heatscrew | Material | Stainless steel |
| Head Type | Hex head | Thread type | Machine thread |
| Threading | Thread fit | ||
| Salt Spray test | 72 hours | Thread Direction | Right hand |
| Drive Type | socket cap | Finish | Passivated |
| Standard | Metric, Inch | Packing | Plastic bag+carton |
| Available size | M2 | M3 | M4 | M5 | M6 | M7 | M8 | M9 | M10 | M12 |
|---|---|---|---|---|---|---|---|---|---|---|
| 4mm | √ | √ | ||||||||
| 9mm | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ |
| 10mm | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ |
| 12mm | √ | √ | √ | √ | √ | √ | √ | √ | ||
| 25mm | √ | √ | √ | √ | √ | √ | √ | √ | √ | |
| 35mm | √ | √ | √ | √ | √ | √ | √ | √ | ||
| 70mm | √ | √ | √ | √ | √ | √ | √ | |||
| 90mm | √ | √ | √ | √ | √ | √ | ||||
| 100mm | √ | √ |
Size not listed? Please make an inquiry – we are able to provide it. Custom fasteners are available
