Heatfastener is an ISO 9001:2015 manufacturer specializing in the Global supply of security screws, SEMS screws, micro screws, custom screws, thumb screws, Chicago screws, custom bolts, custom fasteners, etc.

All of the products are widely used in the medical, instrumentation, aerospace, maritime, microwave, electronics, and chemical equipment industries, we have designed and manufactured key components for world-famous enterprises and are committed to providing our customers with high-quality products, high-level services, and continuous improvement

With ISO9001:2008,iso14001:2004, and especially IAFT16949:2009 certification for the automotive industry. Heatfastener offers fully customized custom bolts and screws according to your needs. We can bring your fastener design to reality, and everything according to your requirements.

security screws

Security Screws Details

security screws, also known as tamperproof screws, Anti-tamper, or tamper-resistant screws, Anti Theft Screws are typically used to secure goods against unwanted tampering. are otherwise standard screws but with a unique head, making it nearly impossible to remove with common tools. That used to mean that any screw that couldn’t be removed with a slot-style or Phillips head driver could be considered a security screw.

Security screws come in a variety of diameters and lengths. We carry them in coarse and fine thread. Listed below are the diameters we carry for all of our custom screws, custom bolts, and other custom fasteners:

Materials:

  • Stainless steel – SS302, SS304, SS316, (good tenacity),Stainless steel A2 A4
  • Steel – C45(K1045), C46(K1046),C20
  • Brass – C36000 ( C26800), C37700 ( HPb59), C38500( HPb58),C27200CuZn37), C28000(CuZn40)
  • Bronze–C51000, C52100, C54400, etc
  • Aluminum – Al6061, Al6063 etc
  • Carbon steel – C1006,C1010,C1018,C1022,C1035K,C1045
  • Alloy steel – SCM435,C10B21,C10B339
  • Other material– Titanium, UNS C11000 Copper,silicon

Others:

  • Grade: Grade 4.8,Grade 6.8,Grade 8.8,Grade10.9,Grade12.9 etc
  • Standard:GB,DIN,ISO, ANSI/ASTM,BS,BSW,JIS, Metric, Inch
  • Finish:Plain, H.D.G, Black oxide, Chrome, Teflon,dacromet,Anodized,With nylok
  • Certificates: ISO9001:2015, ISO14001:2015,IATF16949, ROHS
  • Custom Made:OEM is available,according to customer requirments

Head type&Drive Type

  • Head Type:Flat, Oval, Binding, Pan, Round, Truss, Button, PF,Cheese,Fillister, Pan Washer, Cylinder,Hexagon, Indented Hexagon,Washer
  • Drive Type:Phillips, Slotted, Phiilips/Slotted, 6 Lobe, Pin 6 Lobe, Pozidrive, Square, Triangle,Y type. Tri-wing, S-type, H type, Hexagon, 5 Point,8 point, Spline, Spanner, Clutch, Hex pn,torx pin
  • Machine Screw, Tapping screws,threading cutting screw,threading forming screw

Application

Tamper Proof Fasteners are bolts, Nuts as well as Screws best defined by their non-traditional drive design. Tamper Proof fasteners are made use of in locations where a setting up comes to the general public, as a way to hinder or avoid criminal damage or disassembly. Tamper-resistant safety screws, or anti-theft screws, are differentiated by having an unusual drive, making damaging the products harder, otherwise difficult without the matching correct driver. Security Screws are made use of for safeguarding products from being damaged, such as seamless gutters, permit plates, grills behind bars, institutions, watercraft, and also automobiles. They are likewise utilized in food preparation and also handling locations. You will certainly typically see safety and security screws utilized in washroom stalls, specifically bathroom dividers and also various other public areas.

  • Electronics
  • Petrochemicals
  • Consumer products
  • Transportation
  • Agriculture
  • Heavy machinery
  • Construction
  • Automotive
  • Medical
  • Military
  • Aerospace
  • Oil and gas

Types of Security Screws

  • One Way Security Screw:One way screws are the screws most often used in safes, security gates and hangings in public areas. … Creating a Slot in the Screw An innovative method to remove one way screws is to make slots in which to place your standard screwdriver.
  • (Spanner )Pig Nose (Snake Eye) Security Screw:Pig nose (or 2-hole) fixings are security fasteners with two holes drilled into the head of the fasteners which are used to fasten and remove them, with a special insert drive bit.
  • Pin Hex Security Screw:Pin Hex security fasteners can only be fastened and removed using the matching drill bit or wrench. Also known as Tamper Pin Hex and Socket Screw with Pin.
  • Torx (6 Lobe with Pin) Security Screws:Torx® with pin security drive can only be driven with security bits and are used to prevent tampering and theft. Security Screws in this variety are characterized by the 6 lobe, or star drive with a central pin. The pin grants additional tamper resistance as it prevents conventional screwdrivers and grabbing devices from tampering with the original installation.

We supply all kinds of custom security screws from Micro M1 to Large long M40

SizeM1.6M2M2.5M3M4M5M6M8M10
Thread pitch0.350.40.450.50.70.811.251.5
DK(min)2.93.74.75.77.649.6411.3715.5719.78
dk(max)3.2456810121620
k(min)1.181.481.882.282.953.654.455.857.32
k(max)1.411.722.122.523.253.954.756.157.68
drive sizeT4T6T8T10T20T25T30T40T50
SECURITY SCREW SIZE CHART

Need Custom Screws for Your Industry?

As a 20-year industry experience manufacturer with a factory equipped with precision machines, we can provide, from consultation to production, a one-stop solution for you.

About Us

Shenzhen Heat Hardware Co., Ltd is a leading custom screw manufacturer in China founded in 2000 years. We are specializing in custom screws, security screws, Sems screws, Chicago Screws, Weld Screws, Long screws, Micro Screws, Thumb Screws, Set Screws, Custom bolts, carriage bolts, nuts, and other custom Fasteners. With more than 20years of industry experience. We have serviced over 20000customers including the aerospace industry, automotive industry, electronics, mechanical and electrical products, robots, the Medical industry, communications industry, Outdoor sports products, smart appliances, etc. we can provide one-stop fastener customized service for you no matter what kind of custom fastener you need.

Frequently Asked Questions

What are Anti-tamper fixings? These are fastenings that protect goods and property from thieves using conventional tools such as spanners and screwdrivers to undo threaded fixings. Within this group are security screws with anti-tamper heads including: – Clutch Head security screws

Security Torx Screws (aka Pin Torx Screws or Star Drive Screws) Pin Hex Screws (aka: Security Hex Screws) Snake Eye Screws (aka: Two Hole Screws, Pig Nose bolts or screws) Clutch Head screws (including the pozidriv type Sentinel One Way Screws).

“Proof” means it’s next to impossible. Tamper-resistant theory dictates a screw, bolt, or nut is designed to be installed and removed with a specialized tool made specifically for that fastener. It’s unlikely the average person wanting to loosen such a screw would have anything but ordinary tools available

If the application for your security screws is to achieve a permanent, non-removable fixing then one-way, clutch head screws, which are installed with a standard flat blade screwdriver, or Sentinel One-way screws which are installed with a standard Phillips / cross head screwdriver, would be a good choice

Security Screws are used for securing materials from being tampered with, such as gutters, license plates, grills in jails, schools, boats, and cars. They are also used in food prep and processing areas
